StingRay RS Hero Image
StingRay RS Logo

CUSTOM OPTIONS

Vintage Turquoise

Firemist Silver

Ivory White

Charcoal Frost

Vintage Sunburst (+$100.00)

Coral Red

Stealth Black (+$200.00)

Your Custom Options:

Model:
Color:
Neck:
Pickguard:
Hardware:

Build Code
000-00-00-00

STREET PRICE

$0.00

Guitar Center

(855) 770-3373

Buy Now
Musician's Friend

(801) 501-8110

Buy Now
American Musical Supply

(800) 458-4076

Buy Now
Pitbull audio

(888) 255-6632

Buy Now

StingRay RS Highlights

StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Slide
StingRay RS Highlight
Ernie Ball Music Man Alnico 5 humbuckers
StingRay RS Highlight
Roasted Figured Maple Neck
StingRay RS Highlight
Modern Classic tremolo

Specifications, Schematics & More

Specifications StingRay RS
Model StingRay RS
Size 14-1/16" wide, 1-5/8" thick, 39-1/4" long (35.7 cm wide, 4.1 cm thick, 99.7 cm long)
Weight 7 lbs, 15 oz (3.6 kg) - varies slightly
Body Wood African mahogany
Body Finish High gloss polyester
Body Colors Firemist Silver, Ivory White, Vintage Sunburst, Vintage Turquoise, Charcoal Frost, Coral Red, Stealth Black
Bridge Music Man® Modern tremolo with vintage bent steel saddles
Pickguard Parchment (Firemist Silver, Vintage Turquoise, or Coral Red); Mint (Ivory White); Shell (Vintage Sunburst or Charcoal Frost); Matte Black (Stealth)
Scale Length 25-1/2" (64.8 cm)
Neck Radius 10" (25.4 cm)
Headstock Size 6-3/8" (16.2 cm) long
Frets 22 - High profile, medium width, Stainless Steel
Neck Width 1-5/8" (41.3 mm) at nut, 2-1/4" (56.9 mm) at last fret
Neck Wood Roasted figured maple on all except the Stealth Black (standard maple)
Fingerboard Roasted Figured Maple (Vintage Turquoise, Vintage Sunburst,); Rosewood ( Ivory White, Coral Red Red, or Charcoal Frost); Ebony (Stealth)
Fret Markers 1/4" Black or White Face dots
Neck Finish Hand rubbed oil and wax finish on all but Stealth Black, which features an ultra-light satin polyurethane finish
Tuning Machines Schaller M6-IND locking
Truss Rod Adjustable - no component or string removal
Neck Attachment 5 bolts - perfect alignment with no shifting; Sculpted neck joint allows smooth access to higher frets
Electronic Shielding Chrome plated aluminum control cover (Black on Stealth)
Controls 500kohm volume and tone - .022µF tone capacitor
Switching 3-way toggle pickup selector
Pickups HH - 2 Music Man® custom wound humbucking with chrome covers (Black on Stealth)
Left Handed No
Strings 10p-13p-17p-26w-36w-46w (RPS 10 Slinkys #2240)

id => 71

iid => 71

enabled => 1

header_1 =>

header_2 =>

wiring_image => 0

created_at => 2015-11-06 08:20:42

updated_at => 2015-11-06 08:20:42

Specifications StingRay RS
Model StingRay RS
Order 0
Size 14-1/16" wide, 1-5/8" thick, 39-1/4" long (35.7 cm wide, 4.1 cm thick, 99.7 cm long)
Weight 7 lbs, 15 oz (3.6 kg) - varies slightly
Body Wood African mahogany
Body Finish High gloss polyester
Body Colors Firemist Silver, Ivory White, Vintage Sunburst, Vintage Turquoise, Charcoal Frost, Coral Red, Stealth Black
Body Bindings
Bridge Music Man® Modern tremolo with vintage bent steel saddles
Pickguard Parchment (Firemist Silver, Vintage Turquoise, or Coral Red); Mint (Ivory White); Shell (Vintage Sunburst or Charcoal Frost); Matte Black (Stealth)
Scale Length 25-1/2" (64.8 cm)
Neck Radius 10" (25.4 cm)
Headstock Size 6-3/8" (16.2 cm) long
Frets 22 - High profile, medium width, Stainless Steel
Neck Width 1-5/8" (41.3 mm) at nut, 2-1/4" (56.9 mm) at last fret
Neck Wood Roasted figured maple on all except the Stealth Black (standard maple)
Fingerboard Roasted Figured Maple (Vintage Turquoise, Vintage Sunburst,); Rosewood ( Ivory White, Coral Red Red, or Charcoal Frost); Ebony (Stealth)
Fret Markers 1/4" Black or White Face dots
Neck Finish Hand rubbed oil and wax finish on all but Stealth Black, which features an ultra-light satin polyurethane finish
Neck Colors
Neck Binding
Tuning Machines Schaller M6-IND locking
Truss Rod Adjustable - no component or string removal
Neck Attachment 5 bolts - perfect alignment with no shifting; Sculpted neck joint allows smooth access to higher frets
Electronic Shielding Chrome plated aluminum control cover (Black on Stealth)
Controls 500kohm volume and tone - .022µF tone capacitor
Switching 3-way toggle pickup selector
Pickups HH - 2 Music Man® custom wound humbucking with chrome covers (Black on Stealth)
Left Handed No
Strings 10p-13p-17p-26w-36w-46w (RPS 10 Slinkys #2240)
